LA-401XN
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 10.16MM 1DGT YLW CC
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.2768
≥1 USD $4.2768
≥10 USD $3.02192
Inventory: 55
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 13.0048mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.6V
Display Type 7-Segment
Wavelength - Peak 589nm
Luminous Intensity 90 mcd
Current - Test 10mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 65mW
Operating Supply Voltage 2.05V
Number of Contacts 10
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.512 Hx0.378W x 0.276 D 13.00mmx9.60mmx7.00mm
Published 2005
Packaging Bulk
Physical
Package / Case 10-DIP (0.300, 7.62mm)
Supply Chain
Factory Lead Time 10 Weeks
