LA-401MD
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEG 10.16MM 1DGT GRN CA
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.0152
≥1 USD $2.0152
≥10 USD $1.74064
≥100 USD $1.58136
≥500 USD $1.51309
≥1000 USD $1.50172
Inventory: 53
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.300, 7.62mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2008
Size / Dimension 0.512 Hx0.378W x 0.276 D 13.00mmx9.60mmx7.00mm
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Color Green
Subcategory LED Displays
Number of Functions 1
Depth 9.6mm
Operating Supply Voltage 2.1V
Number of Elements 8
Power Dissipation-Max 60mW
Element Configuration Common Anode
Power Dissipation 480W
Forward Current 20mA
Current - Test 10mA
Luminous Intensity 16 mcd
Wavelength - Peak 563nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Anode
Character Width 5.57mm
Dimensions
Height 13.0048mm
Viewing Area (height) 10.16mm
Character Height 10.16mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
