LA-401BD image
Favorite
LA-401BD image
Favorite
RoHS
RoHS RoHS compliant
Package 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 7SEG 10.16MM 1DGT BLU CA
PDF
/
Buying Options
Total Price: USD $26.81
Unit Price: USD $26.809418
≥1 USD $26.809418
≥240 USD $10.697509
≥480 USD $10.3404
≥960 USD $10.163159
Inventory: 962
Minimum: 1
-
+

Technical Details

Physical

Mount Through Hole
Package / Case 10-DIP (0.300, 7.62mm)

Technical

Packaging Bulk
Published 2008
Size / Dimension 0.512 Hx0.378W x 0.276 D 13.00mmx9.60mmx7.00mm
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Color Blue
Number of Contacts 10
Operating Supply Voltage 3.6V
Power Dissipation-Max 42mW
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 3.6V
Forward Current 10mA
Current - Test 10mA
Forward Voltage 3.6V
Luminous Intensity 56 mcd
Millicandela Rating 56mcd
Illumination Color Blue
Wavelength - Peak 470nm
Display Type 7-Segment
Wavelength 470 nm
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Anode
Character Width 5.57mm

Dimensions

Height 13.0048mm
Width 9.6012mm
Character Height 10.16mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
