LA-301MB
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7-SEG 8MM 1DIGIT GRN CA
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.0152
≥1 USD $2.0152
≥10 USD $1.74064
≥100 USD $1.58136
≥500 USD $1.51309
≥1000 USD $1.50172
Inventory: 169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Character Height 8mm
Viewing Area (height) 8mm
Height 10.9982mm
Technical
Character Width 4mm
Common Pin Common Anode
Digit/Alpha Size 0.31 8.00mm
Number of Segments 7
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 563nm
Luminous Intensity 10 mcd
Current - Test 10mA
Forward Current 20mA
Power Dissipation 480W
Element Configuration Common Anode
Power Dissipation-Max 60mW
Number of Elements 8
Operating Supply Voltage 2.1V
Depth 7mm
Number of Functions 1
Subcategory LED Displays
Color Green
Min Operating Temperature -25°C
Max Operating Temperature 75°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Size / Dimension 0.433 Hx0.276W x 0.197 D 11.00mmx7.00mmx5.00mm
Published 1996
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole
