LA-301BB
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG .315" 1DIGIT BLUE CA
PDF
/
Buying Options
Total Price: USD $20.81
Unit Price: USD $20.805526
≥1 USD $20.805526
≥160 USD $8.301467
≥480 USD $8.024445
≥960 USD $7.887903
Inventory: 7634
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.209, 5.30mm)
Technical
Packaging Bulk
Published 2008
Size / Dimension 0.433 Hx0.276W x 0.197 D 11.00mmx7.00mmx5.00mm
JESD-609 Code e1
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 75°C
Min Operating Temperature -25°C
Color Blue
Subcategory LED Displays
Number of Functions 1
Number of Contacts 10
Operating Supply Voltage 3.6V
Power Dissipation-Max 42mW
Element Configuration Common Anode
Forward Current 10mA
Luminous Intensity 56 mcd
Millicandela Rating 56mcd
Wavelength - Peak 470nm
Display Type 7-Segment
Forward Voltage-Max 4.2V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Anode
Character Width 4mm
Dimensions
Height 5.0038mm
Character Height 8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
