LA-101MA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
SINGLE DIGIT LED NUMERIC DISPLAY
PDF
/
Buying Options
Total Price: USD $21.1
Unit Price: USD $21.1024
≥1 USD $21.1024
≥10 USD $16.5264
Inventory: 130
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 1 Weeks
Physical
Package / Case 10-DIP (1.200, 30.48mm)
Technical
Series LA-101AK
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Green
Subcategory LED Displays
Number of Functions 1
Operating Temperature (Max) 75°C
Operating Temperature (Min) -25°C
Power Dissipation-Max 640mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Millicandela Rating 16mcd
Wavelength - Peak 563nm
Forward Current-Max 0.02A
Display Type 7-Segment
Forward Voltage-Max 5.6V
Number of Characters 1
Digit/Alpha Size 1.00 25.40mm
Common Pin Common Anode
Dimensions
Display Height 25.4mm
Compliance
RoHS Status ROHS3 Compliant
