QBT56R1
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7-Segment QBT56xxz 3 SMART/NORMAL 7SEG NUMERIC LED DISPLAY LED Character Numeric Display Module 2V 20mA 60mcd 70mW
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.030603
≥1 USD $4.030603
≥234 USD $1.608303
≥468 USD $1.554474
≥1053 USD $1.528216
Inventory: 2599
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 12-DIP (0.600, 15.24mm)
Technical
Series QBT56xxz
Size / Dimension 1.480 Hx0.748W x 0.315 D 37.60mmx19.00mmx8.00mm
Part Status Active
Color Red
Number of Functions 3
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 70mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Millicandela Rating 60mcd
Wavelength - Peak 624nm
Forward Current-Max 0.02A
Display Type 7-Segment
Number of Characters 3
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Display Height 14.2mm
Compliance
RoHS Status RoHS Compliant
