LN524YK
RoHS
/
Package 18-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 2 DIGIT AMBER COMMON CATHODE
PDF
/
Inventory: 4419
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 18-DIP
Number of Pins 18
Technical
Packaging Bulk
Published 2001
Size / Dimension 0.748 Hx0.945W x 0.256 D 19.00mmx24.00mmx6.50mm
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Color Amber
Subcategory LED Displays
Number of Functions 2
Reach Compliance Code unknown
Operating Temperature (Max) 80°C
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 600 μcd
Millicandela Rating 0.6mcd
Wavelength - Peak 590nm
Display Type 7-Segment
Number of Characters 2
Digit/Alpha Size 0.43 11.00mm
Common Pin Common Cathode
Dimensions
Height 18.9992mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
