LN524RA
RoHS
/
Package 18-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 2 DIGIT RED COMMON ANODE
PDF
/
Inventory: 4889
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.43 11.00mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 700nm
Millicandela Rating 0.45mcd
Luminous Intensity 450 μcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation-Max 80mW
Operating Temperature (Max) 80°C
Reach Compliance Code unknown
Number of Functions 2
Subcategory LED Displays
Color Red
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Size / Dimension 0.748 Hx0.945W x 0.256 D 19.00mmx24.00mmx6.50mm
Published 2001
Packaging Bulk
Physical
Number of Pins 18
Package / Case 18-DIP
