LN516YK
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 1 DIGIT AMBER COMMON CATHODE
PDF
/
Inventory: 7429
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2001
Size / Dimension 0.748 Hx0.484W x 0.315 D 19.00mmx12.30mmx8.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Amber
Subcategory LED Displays
Number of Functions 1
Reach Compliance Code unknown
Operating Temperature (Max) 80°C
Operating Temperature (Min) -25°C
Power Dissipation-Max 60mW
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Luminous Intensity 800 μcd
Millicandela Rating 0.8mcd
Wavelength - Peak 590nm
Forward Current-Max 0.02A
Display Type 7-Segment
Forward Voltage-Max 2.8V
Number of Characters 1
Digit/Alpha Size 0.57 14.40mm
Common Pin Common Cathode
Dimensions
Height 18.9992mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
