LN513RK
RoHS
/
Package 14-DIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 1 DIGIT RED COMMON CATHODE
PDF
/
Inventory: 9867
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 18.9992mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2.8V
Display Type 7-Segment
Forward Current-Max 0.02A
Wavelength - Peak 700nm
Millicandela Rating 0.4mcd
Luminous Intensity 400 μcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation-Max 60mW
Operating Temperature (Min) -25°C
Operating Temperature (Max) 80°C
Reach Compliance Code unknown
Number of Functions 1
Subcategory LED Displays
Color Red
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Size / Dimension 0.748 Hx0.394W x 0.217 D 19.00mmx10.00mmx5.50mm
Published 2001
Packaging Bulk
Physical
Number of Pins 14
Package / Case 14-DIP
