LN513GKM
RoHS
/
Package 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 1 DIGIT GREEN .3 MINIATURE
PDF
/
Inventory: 3284
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.209, 5.30mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2001
Size / Dimension 0.433 Hx0.276W x 0.197 D 11.00mmx7.00mmx5.00mm
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Color Green
Subcategory LED Displays
Number of Functions 1
Reach Compliance Code unknown
Operating Temperature (Max) 80°C
Operating Temperature (Min) -25°C
Power Dissipation-Max 40mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Luminous Intensity 1 mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Forward Voltage-Max 2.8V
Number of Characters 1
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Cathode
Dimensions
Height 10.9982mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
