MAN6680 image
Favorite
MAN6680 image
Favorite
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG SGL CC ORN RHDP .56"
PDF
/
Inventory: 4123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 630nm
Millicandela Rating 2.2mcd
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 2.5V Max
Power Dissipation-Max 600mW
Color Orange
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.750 Hx0.480W x 0.315 D 19.05mmx12.20mmx8.00mm
Packaging Bulk

Physical

Package / Case 10-DIP (0.600, 15.24mm)
