MAN5760
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG DISP CC RED RHDP .51"
PDF
/
Inventory: 4238
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 17.5006mm
Technical
Character Width 12.954mm
Common Pin Common Cathode
Digit/Alpha Size 0.51 13.00mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 655nm
Millicandela Rating 0.5mcd
Luminous Intensity 500 μcd
Current - Test 20mA
Forward Current 240mA
Element Configuration Common Cathode
Power Dissipation-Max 480mW
Operating Supply Voltage 1.6V
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.689 Hx0.482W x 0.276 D 17.50mmx12.25mmx7.00mm
Packaging Bulk
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Alternative Model
