LDT-N513RI
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7SEG .56" TRI 585NM YLW CC
PDF
/
Inventory: 8987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Package / Case 12-DIP (0.600, 15.24mm), 11 Leads
Technical
Packaging Bulk
Published 2002
Size / Dimension 0.748 Hx1.480W x 0.315 D 19.00mmx37.60mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Yellow
HTS Code 8541.40.20.00
Subcategory LED Displays
Number of Functions 3
Number of Contacts 12
Operating Supply Voltage 2.5V
Power Dissipation-Max 105mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 1.4 mcd
Wavelength - Peak 585nm
Display Type 7-Segment
Forward Voltage-Max 2.6V
Number of Characters 3
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Character Width 13.208mm
Dimensions
Height 18.9992mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
