RoHS
RoHS RoHS compliant
Package 12-DIP (0.600, 15.24mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG .56" 3-DIGIT RED CA
PDF
/
Inventory: 3647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 8.128mm

Technical

Character Width 14.224mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 3
Forward Voltage-Max 2.6V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Millicandela Rating 1.4mcd
Luminous Intensity 2 mcd
Current - Test 20mA
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Anode
Operating Supply Voltage 2.8V
Number of Contacts 12
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx1.480W x 0.315 D 19.00mmx37.60mmx8.00mm
Published 2002
Packaging Bulk

Physical

Package / Case 12-DIP (0.600, 15.24mm), 11 Leads
