LDT-A515RI image
Favorite
LDT-A515RI image
Favorite
RoHS
RoHS RoHS compliant
Package 28-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7SEG .56" TRI 695NM HRED CA
PDF
/
Inventory: 4605
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 18.9992mm

Technical

Character Width 14.224mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 3
Forward Voltage-Max 2.6V
Display Type 7-Segment
Wavelength - Peak 700nm
Luminous Intensity 1.55 mcd
Current - Test 10mA
Forward Current 25mA
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Anode
Power Dissipation-Max 120mW
Operating Supply Voltage 2.5V
Number of Contacts 28
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx1.488W x 0.315 D 19.00mmx37.80mmx8.00mm
Published 2000
Packaging Bulk

Physical

Package / Case 28-DIP (0.600, 15.24mm)

Alternative Model
