LDS-E5006RI image
Favorite
LDS-E5006RI image
Favorite
RoHS
RoHS RoHS compliant
Package 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories LED Display
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.02008
≥1 USD $5.02008
≥10 USD $4.73592
≥100 USD $4.467851
≥500 USD $4.214953
≥1000 USD $3.976377
Inventory: 7833
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 9.398mm

Technical

Character Width 12.7mm
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Display Type 16-Segment, Alphanumeric
Wavelength - Peak 660nm
Luminous Intensity 6 mcd
Current - Test 10mA
Forward Current 30mA
Voltage - Forward (Vf) (Typ) 1.7V
Element Configuration Common Anode
Power Dissipation-Max 100mW
Operating Supply Voltage 2.2V
Number of Contacts 18
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Published 2003
Packaging Bulk

Physical

Package / Case 18-DIP (0.500, 12.70mm)

Supply Chain

Factory Lead Time 12 Weeks
