LDS-C813RI image
Favorite
LDS-C813RI image
Favorite
RoHS
RoHS RoHS compliant
Package 16-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG .80 SNGL YEL CC DIRECT
PDF
/
Inventory: 6081
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 27.7114mm

Technical

Character Width 20.32mm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Forward Voltage-Max 2.6V
Display Type 7-Segment
Wavelength - Peak 585nm
Luminous Intensity 2.5 mcd
Current - Test 10mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Operating Supply Voltage 2.5V
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.091 Hx0.787W x 0.331 D 27.70mmx20.00mmx8.40mm
Published 2002
Packaging Bulk

Physical

Number of Pins 16
Package / Case 16-DIP (0.600, 15.24mm), 13 Leads
