LDS-C504RI
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP Module
PDF
/
Inventory: 6716
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Technical
Packaging Bulk
Published 2002
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 2.5V
Power Dissipation-Max 105mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 3.9 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Forward Voltage-Max 2.6V
Number of Characters 1
Digit/Alpha Size 0.50 12.70mm
Common Pin Common Cathode
Character Width 12.7mm
Dimensions
Height 8mm
Character Height 12.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
