RoHS
RoHS RoHS compliant
Package 10-DIP (2.367, 60.10mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2.25 SNGL RED CA DIR
PDF
/
Inventory: 7169
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Package / Case 10-DIP (2.367, 60.10mm)

Technical

Packaging Bulk
Published 2000
Size / Dimension 2.756 Hx1.890W x 0.472 D 70.00mmx48.00mmx12.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 8V
Power Dissipation-Max 105mW
Element Configuration Common Anode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 9 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 2.24 56.90mm
Common Pin Common Anode
Character Width 58.42mm

Dimensions

Height 70.1mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
