LDS-AD12RI image
Favorite
LDS-AD12RI image
Favorite
RoHS
RoHS RoHS compliant
Package 10-DIP (2.367, 60.10mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2.25 SNGL GRN CA DIR
PDF
/
Inventory: 2533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 12mm

Technical

Character Width 58.42mm
Common Pin Common Anode
Digit/Alpha Size 2.24 56.90mm
Number of Characters 1
Forward Voltage-Max 7.8V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 565nm
Millicandela Rating 6.3mcd
Luminous Intensity 6.3 mcd
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 105mW
Operating Supply Voltage 8.4V
Number of Functions 1
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 2.756 Hx1.890W x 0.472 D 70.00mmx48.00mmx12.00mm
Published 2000
Packaging Bulk

Physical

Package / Case 10-DIP (2.367, 60.10mm)

Supply Chain

Factory Lead Time 12 Weeks
