Package 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 1.0 SNGL RED CA DIRECT
PDF
/
Inventory: 8144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Package / Case 10-DIP (1.200, 30.48mm)
Weight 907.18474mg

Technical

Packaging Bulk
Published 2000
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 80°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 5V
Power Dissipation-Max 105mW
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 4V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 9.8 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Forward Voltage-Max 4.2V
Number of Characters 1
Digit/Alpha Size 1.00 25.40mm
Common Pin Common Anode
Character Width 25.4mm

Dimensions

Height 12.7mm
Character Height 25.4mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
