LDS-AA102RI
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.600, 15.24mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories LED Display
PDF
/
Inventory: 7001
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 14-DIP (0.600, 15.24mm), 11 Leads
Technical
Packaging Bulk
Published 2000
Size / Dimension 1.299 Hx0.886W x 0.335 D 33.00mmx22.50mmx8.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Number of Functions 1
Number of Contacts 14
Operating Supply Voltage 5.2V
Power Dissipation-Max 105mW
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 10mA
Luminous Intensity 5.6 mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 1.02 26.00mm
Common Pin Common Anode
Character Width 25.4mm
Dimensions
Height 10.16mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
