Package 18-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories LED Display
PDF
/
Inventory: 8543
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 18-DIP (0.600, 15.24mm), 13 Leads

Technical

Packaging Bulk
Published 2000
Size / Dimension 0.984 Hx0.732W x 0.417 D 25.00mmx18.60mmx10.60mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Number of Functions 1
Number of Contacts 18
Operating Supply Voltage 2.2V
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Luminous Intensity 5.6 mcd
Millicandela Rating 5.6mcd
Wavelength - Peak 635nm
Power Consumption 105mW
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Anode
Character Width 20.32mm

Dimensions

Height 10.6mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
