LDS-A6004RI
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.800, 20.32mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories LED Display
PDF
/
Inventory: 4445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 8.3mm
Technical
Character Width 15.24mm
Common Pin Common Anode
Digit/Alpha Size 0.59 15.00mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 3.9 mcd
Current - Test 10mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Anode
Power Dissipation-Max 105mW
Operating Supply Voltage 2.5V
Number of Contacts 10
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.984 Hx0.709W x 0.327 D 25.00mmx18.00mmx8.30mm
Published 2000
Packaging Bulk
Physical
Package / Case 10-DIP (0.800, 20.32mm)
