LDS-A356RI
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LUMEX LDS-A356RI7-Segment LED Display, 1, 7.62 mm, Red, Common Anode, 6 mcd, 10 mA
PDF
/
Inventory: 4052
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 7.62mm
Height 6.096mm
Technical
Character Width 7.62mm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 660nm
Millicandela Rating 6mcd
Luminous Intensity 6 mcd
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Element Configuration Common Anode
Operating Supply Voltage 2.2V
Number of Contacts 10
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.500 Hx0.299W x 0.240 D 12.70mmx7.60mmx6.10mm
Published 2003
Packaging Bulk
Physical
Package / Case 10-DIP (0.200, 5.08mm)
