LDD-E302NI-RA
RoHS
RoHS compliant
RoHS compliantPackage 9-SIP Right Angle
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG .30" RA 2-DGT GRN CA
PDF
/
Buying Options
Total Price: USD $2.51
Unit Price: USD $2.510265
≥1 USD $2.510265
≥192 USD $1.001743
≥480 USD $0.96892
≥960 USD $0.951853
Inventory: 6586
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 7.62mm
Height 15.0114mm
Technical
Character Width 7.62mm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 2
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 565nm
Millicandela Rating 2.5mcd
Luminous Intensity 2.5 mcd
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 105mW
Operating Supply Voltage 2.2V
Number of Contacts 9
Number of Functions 2
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.591 Hx0.610W x 0.283 D 15.00mmx15.50mmx7.20mm
Published 2003
Packaging Bulk
Physical
Package / Case 9-SIP Right Angle
Supply Chain
Factory Lead Time 12 Weeks
