RoHS
RoHS RoHS compliant
Package 18-DIP (0.866, 22.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG .80 DUAL RED CC DIRECT
PDF
/
Buying Options
Total Price: USD $3.78
Unit Price: USD $3.777213
≥1 USD $3.777213
≥196 USD $1.507209
≥504 USD $1.457319
≥994 USD $1.432374
Inventory: 3444
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Character Height 20.3mm
Height 10mm

Technical

Character Width 20.32mm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 3.9 mcd
Current - Test 10mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Operating Supply Voltage 2.5V
Number of Functions 2
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.016 Hx1.409W x 0.394 D 25.80mmx35.80mmx10.00mm
Published 2000
Packaging Bulk

Physical

Package / Case 18-DIP (0.866, 22.00mm)

Supply Chain

Factory Lead Time 12 Weeks
