LTS-6975HR

Lite-On Inc.
RoHS
/
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 1DGT RED 0.56" CA
PDF
/
Inventory: 3277
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 0.5
Depth 12.6mm
Number of Elements 5
Element Configuration Common Anode
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 20mA
Luminous Intensity 2.4 mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.8V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 623 nm
Size / Dimension 0.750 Hx0.496W x 0.315 D 19.05mmx12.60mmx8.00mm
Packaging Tube

Dimensions

Height 19.05mm
Viewing Area (height) 14.22mm

Compliance

RoHS Status RoHS Compliant

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
