LTS-6960HR

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 1DGT HER 0.56" CA
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 3687
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Viewing Area (height) 14.22mm
Height 19.05mm

Technical

Character Width 14.224mm
Dominant Wavelength 623 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 2.4 mcd
Current - Test 20mA
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2.6V
Depth 12.6mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.750 Hx0.496W x 0.315 D 19.05mmx12.60mmx8.00mm
Published 2010
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
