LTS-6780P
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED 0.56" CC
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.174483
≥1 USD $1.174483
≥10 USD $1.108007
≥100 USD $1.045287
≥500 USD $0.986122
≥1000 USD $0.930302
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 14.22mm
Height 19.05mm
Technical
Dominant Wavelength 657 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 697nm
Millicandela Rating 0.95mcd
Luminous Intensity 950 μcd
Current - Test 20mA
Forward Current 15mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 40mW
Element Configuration Common Cathode
Number of Elements 8
Depth 12.6mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.750 Hx0.496W x 0.315 D 19.05mmx12.60mmx8.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
