LTS-546AHR
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT HER 0.52" CA
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.459945
≥1 USD $1.459945
≥200 USD $0.582928
≥480 USD $0.563234
≥1000 USD $0.554044
Inventory: 1189
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 13.2mm
Height 17.5514mm
Technical
Character Width 13.208mm
Dominant Wavelength 623 nm
Common Pin Common Anode
Digit/Alpha Size 0.52 13.21mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 100mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2.6V
Reach Compliance Code not_compliant
Depth 12.4mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.691 Hx0.488W x 0.276 D 17.55mmx12.40mmx7.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
