LTS-50301G
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (5.197, 132.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 5.0" 1DIGIT GREEN CC
PDF
/
Inventory: 5049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 127mm
Technical
Dominant Wavelength 569 nm
Common Pin Common Cathode
Digit/Alpha Size 5.00 127.00mm
Number of Characters 1
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 565nm
Luminous Intensity 60 mcd
Current - Test 30mA
Forward Current 60mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 21V
Power Dissipation 1.2W
Element Configuration Common Cathode
Number of Elements 222
Depth 108mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 7.087 Hx4.252W x 0.630 D 180.00mmx108.00mmx16.00mm
Published 2012
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (5.197, 132.00mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
