LTS-4801JF
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG .40" 1DGT YELL-ORNG CA
PDF
/
Inventory: 7074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10mm
Height 7.0104mm
Technical
Dominant Wavelength 605 nm
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 611nm
Illumination Color Orange
Millicandela Rating 0.65mcd
Luminous Intensity 650 μcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.05V
Power Dissipation 70mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2.6V
Depth 9.7mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Orange-Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.508 Hx0.382W x 0.276 D 12.90mmx9.70mmx7.00mm
Published 2001
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
