LTS-4740AP
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED 0.40" CC
PDF
/
Inventory: 6990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10.16mm
Height 18.7452mm
Technical
Dominant Wavelength 657 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 697nm
Millicandela Rating 0.8mcd
Luminous Intensity 800 μcd
Current - Test 20mA
Forward Current 15mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 40mW
Element Configuration Common Cathode
Number of Elements 8
Reach Compliance Code unknown
Depth 19.9mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Published 2000
Packaging Tube
Physical
Number of Pins 13
Package / Case 14-DIP (0.300, 7.62mm), 13 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
