LTS-3731E
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT ORANGE 0.43" CARLD
PDF
/
Inventory: 2132
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 14-DIP (0.300, 7.62mm)
Technical
Packaging Tube
Size / Dimension 0.744 Hx0.496W x 0.310 D 18.90mmx12.60mmx7.87mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Orange-Red
Subcategory LED Displays
Number of Functions 1
Reach Compliance Code unknown
Power Dissipation-Max 75mW
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 2.2 mcd
Illumination Color Orange
Wavelength - Peak 630nm
Display Type 7-Segment
Forward Voltage-Max 2.8V
Number of Characters 1
Digit/Alpha Size 0.43 11.00mm
Common Pin Common Anode
Dominant Wavelength 621 nm
Character Width 10.922mm
Dimensions
Height 18.8976mm
Viewing Area (height) 11mm
Compliance
RoHS Status RoHS Compliant
