LTS-368P
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm), 9 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED 0.36" CC
PDF
/
Inventory: 5473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm), 9 Leads
Number of Pins 10
Technical
Packaging Tube
Published 2000
Size / Dimension 0.551 Hx0.295W x 0.332 D 14.00mmx7.50mmx8.44mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 0.5
Depth 7.5mm
Reach Compliance Code unknown
Number of Elements 5
Element Configuration Common Cathode
Power Dissipation 40mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 15mA
Current - Test 20mA
Luminous Intensity 750 μcd
Millicandela Rating 0.75mcd
Wavelength - Peak 697nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.8V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.33 8.30mm
Common Pin Common Cathode
Dominant Wavelength 657 nm
Dimensions
Height 13.9954mm
Viewing Area (height) 8.3mm
Compliance
RoHS Status ROHS3 Compliant
