LTS-3403LY
RoHS
/
Package 18-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT YLW 0.80" CCRLD
PDF
/
Inventory: 6268
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Dominant Wavelength 588 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Forward Voltage-Max 2.8V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 585nm
Millicandela Rating 2.4mcd
Luminous Intensity 2.4 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 60mW
Element Configuration Common Cathode
Number of Elements 9
Reach Compliance Code unknown
Depth 19.9mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Yellow
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.090 Hx0.783W x 0.330 D 27.69mmx19.90mmx8.38mm
Published 2000
Packaging Tube
Physical
Number of Pins 13
Package / Case 18-DIP (0.600, 15.24mm), 13 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
