LTS-3403LP
RoHS
/
Package 18-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED 0.80" CCRLD
PDF
/
Inventory: 4193
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Forward Voltage-Max 2.8V
Display Type 7-Segment
Power Consumption 40mW
Wavelength - Peak 697nm
Millicandela Rating 0.95mcd
Luminous Intensity 950 μcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 40mW
Operating Supply Voltage 2.1V
Reach Compliance Code unknown
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 1.090 Hx0.783W x 0.330 D 27.69mmx19.90mmx8.38mm
Packaging Tube
Physical
Package / Case 18-DIP (0.600, 15.24mm), 13 Leads
Supply Chain
Factory Lead Time 10 Weeks
