LTS-3403LJD
RoHS
RoHS compliant
RoHS compliantPackage 17-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED LC 0.80" CCRLD
PDF
/
Inventory: 5060
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Dominant Wavelength 639 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 650nm
Millicandela Rating 0.7mcd
Luminous Intensity 700 μcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 70mW
Reach Compliance Code unknown
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.090 Hx0.783W x 0.330 D 27.69mmx19.90mmx8.38mm
Published 2001
Packaging Tube
Physical
Package / Case 17-DIP (0.600, 15.24mm), 13 Leads
Supply Chain
Factory Lead Time 12 Weeks
