LTS-3403JS
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT YLW LC 0.80" CCRLD
PDF
/
Inventory: 4574
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Dominant Wavelength 587 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 588nm
Millicandela Rating 0.7mcd
Luminous Intensity 700 μcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.05V
Power Dissipation 40mW
Element Configuration Common Cathode
Number of Elements 9
Reach Compliance Code unknown
Depth 19.9mm
Number of Functions 1
Color Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.090 Hx0.783W x 0.330 D 27.69mmx19.90mmx8.38mm
Published 2000
Packaging Tube
Physical
Number of Pins 13
Package / Case 18-DIP (0.600, 15.24mm), 13 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
