LTS-312AHR

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 14-DIP (0.300, 7.62mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description HI RED LED 7 SEG
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.32
≥1 USD $1.32
≥10 USD $0.833184
≥100 USD $0.616616
≥500 USD $0.566614
≥1000 USD $0.46662
≥3000 USD $0.443291
Inventory: 1701
Minimum: 1
-
+

Technical Details

Technical

Common Pin Common Anode
Dominant Wavelength 623 nm
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Number of LEDs 8
Wavelength 623 nm
Reverse Voltage 5V
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 635nm
Peak Reverse Current 100μA
Illumination Color Red
Millicandela Rating 2mcd
Luminous Intensity 2 mcd
Forward Voltage 2V
Current - Test 20mA
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Anode
Power Dissipation-Max 75mW
Number of Elements 8
Operating Supply Voltage 2V
Number of Contacts 14
Depth 9.85mm
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.738 Hx0.388W x 0.200 D 18.75mmx9.85mmx5.08mm
Published 2000
Packaging Tube

Dimensions

Height 18.7452mm
Length 18.75mm
Width 9.906mm
Viewing Area (height) 7.65mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm), 11 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
