LTS-312AE
RoHS
/
Package 14-DIP (0.300, 7.62mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT ORANGE 0.30" CARLD
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.219195
≥1 USD $1.219195
≥10 USD $1.150184
≥100 USD $1.085075
≥500 USD $1.023657
≥1000 USD $0.965714
Inventory: 1109
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 7.65mm
Height 18.7452mm
Technical
Dominant Wavelength 621 nm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 630nm
Illumination Color Orange
Luminous Intensity 2 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 2V
Reach Compliance Code unknown
Depth 9.85mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.738 Hx0.388W x 0.200 D 18.75mmx9.85mmx5.08mm
Published 2000
Packaging Tube
Physical
Number of Pins 10
Package / Case 14-DIP (0.300, 7.62mm), 11 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
