LTS-2301AG
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT GREEN 0.28" CC
PDF
/
Inventory: 2961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 7mm
Height 10.0076mm
Technical
Dominant Wavelength 569 nm
Common Pin Common Cathode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 565nm
Luminous Intensity 2 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 8
Reach Compliance Code unknown
Depth 10mm
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394 Hx0.291W x 0.240 D 10.00mmx7.40mmx6.10mm
Published 2000
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
