LTS-10304WC
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (1.100, 27.94mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 1DGT RED LC 1.0" CCR&LHD
PDF
/
Inventory: 4677
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 25.4mm
Height 32.9946mm
Technical
Dominant Wavelength 638 nm
Common Pin Common Cathode
Digit/Alpha Size 1.00 25.40mm
Number of Characters 1
Reverse Voltage 10V
Display Type 7-Segment
Wavelength - Peak 660nm
Luminous Intensity 7.5 mcd
Current - Test 5mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 3.4V
Power Dissipation 120mW
Element Configuration Common Cathode
Number of Elements 15
Reach Compliance Code unknown
Depth 22.8mm
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.299 Hx0.898W x 0.354 D 33.00mmx22.80mmx9.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 14
Package / Case 14-DIP (1.100, 27.94mm), 10 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
