LTP-587HR
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED ALPHANUM 0.5" HI-EFF RED CA
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489258
≥1 USD $2.489258
≥200 USD $0.993865
≥500 USD $0.961043
≥1000 USD $0.943975
Inventory: 1429
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 12.7mm
Technical
Dominant Wavelength 623 nm
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Forward Voltage-Max 2.8V
Reverse Voltage 5V
Display Type 16-Segment, Alphanumeric
Power Consumption 75mW
Wavelength - Peak 635nm
Millicandela Rating 2.2mcd
Luminous Intensity 2.2 mcd
Forward Current 20mA
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 17
Operating Supply Voltage 2V
Reach Compliance Code not_compliant
Depth 16mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Published 2000
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.500, 12.70mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
