LTP-4823P
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY ALPHA-NUM RED 0.40" CA
PDF
/
Inventory: 5149
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10mm
Height 16.002mm
Technical
Dominant Wavelength 657 nm
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 2
Display Type 16-Segment, Alphanumeric
Forward Current-Max 0.015A
Wavelength - Peak 697nm
Millicandela Rating 0.75mcd
Luminous Intensity 750 μcd
Current - Test 20mA
Optoelectronic Device Type 16 SEG ALPHANUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 40mW
Reach Compliance Code unknown
Number of Functions 2
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.630 Hx0.795W x 0.276 D 16.00mmx20.20mmx7.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 20
Package / Case 20-DIP (0.500, 12.70mm)
Supply Chain
Factory Lead Time 12 Weeks
