LTG-0122M
RoHS
/
Package 15-SIP
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY GRAPHIC ALHA-NUM R/G 6MM
PDF
/
Inventory: 8852
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Package / Case 15-SIP
Number of Pins 15
Technical
Packaging Tray
Published 2003
Size / Dimension 0.610 Hx2.028W x 0.315 D 15.50mmx51.50mmx8.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Green, Orange-Red
Additional Feature HIGH RELIABILITY
Number of Functions 6
Depth 15.5mm
Reach Compliance Code unknown
Number of Elements 54
Element Configuration Common Anode
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 10mA
Luminous Intensity 1.6 mcd
Wavelength - Peak 565nm 630nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 6
Digit/Alpha Size 0.24 6.00mm
Common Pin Common Anode
Dimensions
Height 15.494mm
Viewing Area (height) 6mm
Compliance
RoHS Status RoHS Compliant
