LTD-6640E
RoHS
/
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 2DIGIT ORN 0.56" CC
PDF
/
Inventory: 2218
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 14.22mm
Height 19.05mm
Technical
Dominant Wavelength 621 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 630nm
Luminous Intensity 2.4 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 16
Reach Compliance Code unknown
Depth 19.05mm
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.750 Hx0.984W x 0.315 D 19.05mmx25.00mmx8.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
